TECHNICAL
| Light Source | Lumiled |
|---|
| Body | PC/PMMA |
|---|
| Colour Temperature | 5000K |
|---|
| Average LED & Control Gear Life Projection | >78,000 hrs – L70 |
|---|
| Beam Angle | 120 degree |
|---|
| Efficacy | 150 Lm/W |
|---|
| CRI | >80 |
|---|
| Max Junction Temperature | 150°C |
|---|
| Cooling | Conduction, Convection |
|---|
| Operating Range | -20°C ~ 50°C |
|---|
| Thermal Management | Aluminium Heatsink |
|---|
ELECTRICAL
| Power Supply | ELV 23-35VAC, 22-48VDC |
|---|
| Protection | Over Voltage, Short Circuit and Over Temperature |
|---|
| Power Factor | >0.96 |
|---|
| Ingress Protection Rating | IP69K (IP67) |
|---|
| Impact Rating | IK10 |
|---|
| Certification | RCM |
|---|
ORDER CODES
| Model | Wattage | Light Colour | Lumens | Dimensions | A | B |
|---|
| RWP69K-1200-ELV | 40W | 5000K | 6000 | 1200 x 70mm | 3.3mm | 70mm |
KEY FEATURES
| Impact Resistant |
| Corrosion Resistant |
| Extra low voltage area lighting |
| Temporary lighting |
| Task lighting |
